100117W-MIL
IC AND/OR GATE 3-CIR 24-CDIP
Manufacturer: National SemiconductorIC code: 2156-100117W-MIL-ND
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
AND/OR Gate Configurable 3 Circuit 12 Input (2, 2, 2, 2, 2, 2) Input 24-CDIP
Specifications
- Series
- -
- Packaging
- Bulk
- Logic Type
- AND/OR Gate
- Output Type
- Differential
- Part Status
- Active
- Manufacturer
- National Semiconductor
- Mounting Type
- Through Hole
- Package / Case
- 24-CDIP (0.400", 10.16mm)
- Number of Inputs
- 12 Input (2, 2, 2, 2, 2, 2)
- Voltage - Supply
- -4.2V ~ -5.7V
- Number of Circuits
- 3
- Base Product Number
- 100117
- Operating Temperature
