BD0810J50150AHF
BALUN 800MHZ-1GHZ 50/150 0805
Manufacturer: TTM Technologies, Inc.IC code: 1173-BD0810J50150AHFTR-ND - Tape & Reel (TR) || 1173-BD0810J50150AHFCT-ND - Cut Tape (CT) || 1173-BD0810J50150AHFDKR-ND - Digi-Reel®
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
RF Balun 800MHz ~ 1GHz 50 / 150Ohm 0805 (2012 Metric)
Specifications
- Series
- Xinger®
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Part Status
- Active
- Manufacturer
- TTM Technologies, Inc.
- Mounting Type
- Surface Mount
- Package / Case
- 0805 (2012 Metric)
- Frequency Range
- 800MHz ~ 1GHz
- Phase Difference
- 6°
- Return Loss (Min)
- 19.6dB
- Base Product Number
- BD0810
- Insertion Loss (Max)
- 0.9dB
- Impedance - Unbalanced/Balanced
- 50 / 150Ohm
