ELJ-NCR12JF
FIXED IND 120NH 170MA 870MOHM SM
Manufacturer: Panasonic Electronic ComponentsIC code: PCD1209TR-ND - Tape & Reel (TR) || PCD1209CT-ND - Cut Tape (CT) || PCD1209DKR-ND - Digi-Reel®
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
120 nH Unshielded Wirewound Inductor 170 mA 870mOhm Max 1008 (2520 Metric)
Specifications
- Mfr
- Panasonic Electronic Components
- Type
- Wirewound
- Series
- NC
- Ratings
- -
- Q @ Freq
- 10 @ 25.2MHz
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Shielding
- Unshielded
- Tolerance
- ±5%
- Inductance
- 120 nH
- Part Status
- Obsolete
- Mounting Type
- Surface Mount
- Package / Case
- 1008 (2520 Metric)
- Material - Core
- Non-Magnetic
- Size / Dimension
- 0.098" L x 0.079" W (2.50mm x 2.00mm)
- Base Product Number
- ELJ-NCR
- DC Resistance (DCR)
- 870mOhm Max
- Current Rating (Amps)
- 170 mA
- Height - Seated (Max)
- 0.071" (1.80mm)
