Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
15 Position Receptacle, Bottom or Top Entry Connector 0.100" (2.54mm) Surface Mount Tin
Specifications
- Mfr
- Harwin Inc.
- Style
- Board to Board
- Series
- M20
- Features
- -
- Packaging
- Tube
- Part Status
- Active
- Termination
- Solder
- Applications
- General Purpose
- Contact Type
- Female Socket
- Contact Shape
- Square
- Mounting Type
- Surface Mount
- Connector Type
- Receptacle, Bottom or Top Entry
- Fastening Type
- Push-Pull
Pitch - Mating0.100" (2.54mm) Contact MaterialPhosphor Bronze Insulation Height0.295" (7.50mm) Base Product NumberM20-786 Insulation MaterialPolyamide (PA6T), Nylon 6T Operating Temperature-40°C ~ 105°C Mated Stacking Heights10.04mm, 11.63mm Contact Finish - MatingTin Number of Positions LoadedAll Material Flammability RatingUL94 V-0 Contact Finish Thickness - Post- Contact Finish Thickness - Mating- Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Tube | 1 | ¥12.24000 |
| Tube | 15 | ¥10.11667 |
| Tube | 105 | ¥8.81743 |
| Tube | 510 | ¥7.88633 |
| Tube | 1,005 | ¥7.51771 |
| Tube | 5,010 | ¥6.71244 |
| Tube | 10,005 | ¥6.39306 |
