MF-USMF150-2
PTC RESET FUSE 6V 1.5A 1210
Manufacturer: Bourns Inc.IC code: MF-USMF150-2TR-ND - Tape & Reel (TR) || MF-USMF150-2CT-ND - Cut Tape (CT) || MF-USMF150-2DKR-ND - Digi-Reel® Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Polymeric PTC Resettable Fuse 6V 1.5 A Ih Surface Mount 1210 (3225 Metric), Concave
Specifications
- Type
- Polymeric
- Grade
- Automotive
- Series
- Multifuse®, MF-USMF
- Ratings
- -
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Part Status
- Active
- Lead Spacing
- -
- Manufacturer
- Bourns Inc.
- Time to Trip
- 5 s
- Current - Max
- 40 A
- Mounting Type
- Surface Mount
- Qualification
- AEC-Q200
- Voltage - Max
- 6V
Package / Case1210 (3225 Metric), Concave Approval AgencycURus, TUV Thickness (Max)0.033" (0.85mm) Size / Dimension0.127" L x 0.102" W (3.22mm x 2.58mm) Base Product NumberMF-USMF Operating Temperature-40°C ~ 85°C Current - Hold (Ih) (Max)1.5 A Resistance - Initial (Ri) (Min)30 mOhms Resistance - Post Trip (R1) (Max)110 mOhms Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) & Digi-Reel® | 1 | ¥6.20000 |
| Cut Tape (CT) & Digi-Reel® | 5 | ¥5.11000 |
| Cut Tape (CT) & Digi-Reel® | 10 | ¥4.71400 |
| Cut Tape (CT) & Digi-Reel® | 50 | ¥3.91180 |
| Cut Tape (CT) & Digi-Reel® | 100 | ¥3.60900 |
| Cut Tape (CT) & Digi-Reel® | 250 | ¥3.24448 |
| Cut Tape (CT) & Digi-Reel® | 500 | ¥2.99242 |
| Cut Tape (CT) & Digi-Reel® | 1,000 | ¥2.75912 |
| Tape & Reel (TR) | 3,000 | ¥2.42371 |
| Tape & Reel (TR) | 6,000 | ¥2.23177 |
| Tape & Reel (TR) | 9,000 | ¥2.12597 |
| Tape & Reel (TR) | 15,000 | ¥2.06750 |
