Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
2 Circuit IC Switch 2:1 18-X2QFN (2.4x2)
Specifications
- Series
- -
- Crosstalk
- -50dB @ 2.5GHz
- Packaging
- Tape & Reel (TR) || Cut Tape (CT) || Digi-Reel®
- Part Status
- Active
- Manufacturer
- NXP USA Inc.
- Mounting Type
- Surface Mount
- -3db Bandwidth
- -
- Package / Case
- 18-XFQFN Exposed Pad
- Switch Circuit
- SPDT
- Charge Injection
- -
- Number of Circuits
- 2
- Base Product Number
- PTN36043
- Operating Temperature
Supplier Device Package18-X2QFN (2.4x2) On-State Resistance (Max)- Voltage - Supply, Dual (V±)- Switch Time (Ton, Toff) (Max)- Voltage - Supply, Single (V+)1.7V ~ 1.9V Current - Leakage (IS(off)) (Max)6µA Multiplexer/Demultiplexer Circuit2:1 Channel-to-Channel Matching (ΔRon)- Channel Capacitance (CS(off), CD(off))- Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) & Digi-Reel® | 1 | ¥19.16000 |
| Cut Tape (CT) & Digi-Reel® | 10 | ¥14.69900 |
| Cut Tape (CT) & Digi-Reel® | 25 | ¥14.63720 |
| Cut Tape (CT) & Digi-Reel® | 100 | ¥13.26400 |
| Cut Tape (CT) & Digi-Reel® | 250 | ¥12.68548 |
| Cut Tape (CT) & Digi-Reel® | 500 | ¥11.38466 |
| Cut Tape (CT) & Digi-Reel® | 1,000 | ¥10.16426 |
| Cut Tape (CT) & Digi-Reel® | 2,500 | ¥9.48661 |
| Cut Tape (CT) & Digi-Reel® | 5,000 | ¥9.06312 |
| Tape & Reel (TR) | 10,000 | ¥8.91084 |
