SM2011-R20MHF
0.2UH, 20%, 4.2MOHM, 26.5AMP MAX
Manufacturer: ITG Electronics, Inc.IC code: 3013-SM2011-R20MHFTR-ND - Tape & Reel (TR)
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
200 nH Inductor 15 A 4.5mOhm Max 2-SMD, J-Lead
Specifications
- Mfr
- ITG Electronics, Inc.
- Type
- -
- Series
- SM2011
- Packaging
- Tape & Reel (TR)
- Tolerance
- ±20%
- Inductance
- 200 nH
- Part Status
- Active
- Mounting Type
- Surface Mount
- Package / Case
- 2-SMD, J-Lead
- Material - Core
- Metal
- Size / Dimension
- 0.224" L x 0.213" W (5.70mm x 5.40mm)
- DC Resistance (DCR)
- 4.5mOhm Max
- Current Rating (Amps)
- 15 A
- Height - Seated (Max)
- 0.118" (3.00mm)
- Operating Temperature
- -55°C ~ 150°C
- Supplier Device Package
- 2-SMD
- Current - Saturation (Isat)
- 26.5A
- Inductance Frequency - Test
