STX-353K7A-6N-KTTR
STEREO JACK 3.5MM 4 POLE 4P VERT
Manufacturer: Kycon, Inc.IC code: 2092-STX-353K7A-6N-KTTR-ND - Tape & Reel (TR) || 2092-STX-353K7A-6N-KTTRCT-ND - Cut Tape (CT) Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
3.50mm (0.141", 1/8", Mini Plug) - Headphone Phone Jack 5 Conductor (TRRRS) Connector Solder
Specifications
- Mfr
- Kycon, Inc.
- Gender
- Female
- Series
- STX-353
- Features
- -
- Includes
- -
- Packaging
- Tape & Reel (TR) || Cut Tape (CT)
- Shielding
- Unshielded
- Body Color
- Black
- Part Status
- Active
- Termination
- Solder
- Thread Size
- -
- Signal Lines
- 5 Conductor (TRRRS)
- Body Material
- -
Mounting TypeThrough Hole Actual Diameter0.142" (3.60mm) Contact MaterialCopper Alloy, Stainless Steel Housing MaterialThermoplastic Internal Switch(s)Single Switch Operating Temperature-40°C ~ 85°C Contact Material - PlatingGold Number of Positions/Contacts5 Conductors, 6 Contacts Industry Recognized Mating Diameter3.50mm (0.141", 1/8", Mini Plug) - Headphone Pricing tiers
| Packaging | Qty | Unit price |
|---|
| Cut Tape (CT) | 1 | ¥17.45000 |
| Cut Tape (CT) | 10 | ¥14.82000 |
| Cut Tape (CT) | 25 | ¥13.89360 |
| Cut Tape (CT) | 50 | ¥13.22860 |
| Cut Tape (CT) | 100 | ¥12.59600 |
| Tape & Reel (TR) | 300 | ¥11.65600 |
| Tape & Reel (TR) | 600 | ¥11.09957 |
| Tape & Reel (TR) | 900 | ¥10.78646 |
| Tape & Reel (TR) | 1,500 | ¥10.40481 |
| Tape & Reel (TR) | 2,100 | ¥10.16087 |
| Tape & Reel (TR) | 3,000 | ¥9.90852 |
| Tape & Reel (TR) | 7,500 | ¥9.28882 |
