UMY1N-TP
TRANS NPN/PNP 50V 150MA SOT-353
Manufacturer: MCC (Micro Commercial Components)IC code: UMY1N-TP-ND - Tape & Reel (TR)
Request this MPN now. Sourcing more than one part? Upload your BOM and we can consolidate component sourcing into one quotation.
Description
Bipolar (BJT) Transistor Array 1 NPN, 1 PNP (Emitter Coupled) 50V 150mA 140MHz 150mW Surface Mount SOT-353
Specifications
- Series
- -
- Packaging
- Tape & Reel (TR)
- Part Status
- Obsolete
- Power - Max
- 150mW
- Manufacturer
- MCC (Micro Commercial Components)
- Mounting Type
- Surface Mount
- Package / Case
- 5-TSSOP, SC-70-5, SOT-353
- Transistor Type
- 1 NPN, 1 PNP (Emitter Coupled)
- Base Product Number
- UMY1
- Operating Temperature
- 150°C (TJ)
- Frequency - Transition
- 140MHz
- Supplier Device Package
- SOT-353
- Vce Saturation (Max) @ Ib, Ic
- 500mV @ 5mA, 50mA
- Current - Collector (Ic) (Max)
- 150mA
- Current - Collector Cutoff (Max)
- 100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce
- 120 @ 1mA, 6V
- Voltage - Collector Emitter Breakdown (Max)
